Pre Engineered Building

• Color
• Blue, White, Customized

• Connection
• Bolted/Welded

• Dimension (L*W*H)
• Customized

• Door
• Other, Custom Size Available

• Door Material
• Other, Steel, Aluminium

• Earthquake Intensity
• Designed for Zone IV & V

• Floor Load
• 250 kg/sq.m

• Floor Material
• Concrete

• Insulation
• Other, Optional Rockwool, Glasswool, EPS

• Life Span
• 30-50 Years

• Material
• Other , Mild Steel, Galvanized Steel

• Open Style
• Other, Sliding, Hinged

• Roof Dead Load
• Not more than 60 kg/sq.m

• Roof Live Load
• 0.5-1.0 kN/m

• Roof Material
• Other, Galvanized Steel Sheet

• Thickness Of Wall Panel
• 50-100 mm

• Use
• Other, Warehouse, Factory, Workshop, Industrial Shed, Storage

• Wall Materials
• Other, Steel Sheet, PUF Panel, EPS Panel

• Window
• Other, Custom Size Available

• Window Material
• Other, Aluminium, uPVC

• Window Style
• Other, Sliding, Fixed

• Color
• Standard Grey, Blue, and customizable as per RAL codes

• Connection
• High-tensile bolted connection system

• Dimension (L*W*H)
• As per client requirements, modular design

• Door
• Other, Single/Double Door, Sliding, or Rolling Shutter

• Door Material
• Other, Steel or Aluminium, insulated options available

• Earthquake Intensity
• Up to Seismic Zone IV compliant

• Floor Load
• 250 kg/m (standard), customizable on request

• Floor Material
• Mild Steel with anti-corrosive coating

• Insulation
• Other, PUF, EPS or Rockwool insulation available

• Life Span
• Approx. 25-30 years with proper maintenance

• Material
• Other , High-tensile Steel Grade 350/550

• Open Style
• Other, Sliding, Swing or Roller Shutter

• Roof Dead Load
• 50 kg/m

• Roof Live Load
• 0.75 kN/m (standard), customizable

• Roof Material
• Other, Galvanized Steel Sheet

• Thickness Of Wall Panel
• 50mm - 100mm, depending on insulation needs

• Use
• Other, Warehouses, Industrial Sheds, Factories, Workshops

• Wall Materials
• Other, Insulated Sandwich Panels

• Window
• Other, Single/Double Glazed options available

• Window Material
• Other, PVC or Aluminum with clear/tinted glass

• Window Style
• Other, Sliding or Fixed
